MARL Training Paradigms

There are four kinds of training paradigms in the research of multi-agent reinforcement learning.

  • Independent Learning: agents in an environment do not share policies, and no coordination between them, all of them optimize their own policies in an indenedent manner. Obviously, such a learning paradigm is also the learning paradigm for single-agent cases.

  • Centralized Training Decentralized Execution: agents play their policies as single-agent cases, i.e., no coordination in the inference stage, but the training requires information from all of them, i.e., a shared critic or non-shared critics but share the information.

  • Fully Centrlized Learning: agents are capsulated into a single policy/network, the training and inference behavior as a big team agent.

  • Networked (distributed) Learning: this training paradigms is designed for some cases that involves hundreds of agents, in this case, the agent coordinate with only its neighbors (mathematically).

To cover the existing research in multi-agent reinforcement learning, we abstract the training paradigm as AgentInterface. An AgentInterface is responsbile for the coordination between parameter server and dataset server, sometimes the other agent interfaces. To satisfy the requirements of population-based learning, an AgentInterface also maintaines a policy population

Independent AgentInterface

An IndependentAgent is responsible for the training of an environment agent, or a shared group of agents. The coordination with parameter server and dataset server is unidirectional, as it only update the remote parameter version and pull training data from remote dataset server. See api/malib.agent.indepdent_agent for more details.

_images/independent_agent.png

Overview of the architecture of IndependentAgent

Team AgentInterface

An TeamAgent is responsible for a group of agents that do not share a common policy pool. In this case, there would be multiple policy pools that are related to agents. And most importantly, there would be some coordination between them. For example, QMIX shares a common critic. See api/malib.agent.indepdent_agent for more details. The TeamAgent supports both two training paradigms, i.e., Centralized Training Decentralized Execution and Fully-centralized Training.

_images/team_agent.png

Overview of the architecture of IndependentAgent

Asynchronous AgentInterface

The AsynchronousAgent is responsbile for the

See api/malib.agent.indepdent_agent

_images/async_agent.png

Overview of the architecture of IndependentAgent
